MD600S INOVANCE DRIVE 0.5 HP

Name: MD600S INOVANCE DRIVE 0.5 HP
Brand: SYSTEM CONTROLS
Price: 5600.0 INR
Availability: InStock

Price 5600.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

MD600S INOVANCE DRIVE 0.5 HP Specification

Operating Temperature
-10C to +50C

Overheating Protection
Built-in Thermal Protection

Power Factor
>=0.98

Insulation Material
High-grade Insulation Polymer

Shape
Rectangular

Connector Type
Terminal Block

Mounting Type
Wall or Panel Mounted

IP Rating
IP 65

Humidity %
95% (non-condensing)

Feature
Compact Design, User-Friendly Interface, Programmable, Soft Start/Stop

Efficiency
Up to 98%

Surface Finish
Textured

Product Type
AC Frequency Inverter Drive

Application
Industrial Motor Control, Automation, HVAC, Pumps, Fans

Protection Level
Overload, Overvoltage, Undervoltage, Short Circuit, IP65

Frequency (MHz)
50/60 Hz

Rated Voltage
230V AC

Energy Consumption
Highly Efficient (as per Load)

Output Type
3 Phase

Color
Grey & Blue

Dimension (L*W*H)
175 mm x 100 mm x 135 mm

Weight
1.2 kg

Size
Standard

Phase
Single Phase

Input Voltage
230V Volt (V)

Material
ABS Plastic, Metal

Connection Type
Screw Terminal

No Of Poles
Variable (Drive Application)

MD600S INOVANCE DRIVE 0.5 HP Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
6 Days

About MD600S INOVANCE DRIVE 0.5 HP

Features & functions :
Compact footprint
Dual network ports for CAN communication, tool-free crimp terminals Energy saving algorithms
Thermosyphon Technology for cooling
Drive board coated with 100% tri-proof coating
Independent air duct + intelligent fan for cooling Support V/F & SVC control function

Note : This drive has Single Phase input and Three Phase output
Model Number : MD600S-2S2R8-INT

Reliable and Versatile Motor Control

The MD600S INOVANCE DRIVE 0.5 HP seamlessly controls industrial motors with precision, using advanced V/F and sensorless vector control. Its high start-up torque and instant fault reaction time ensure motors start reliably, even under demanding tasks. The built-in braking unit helps regulate speeds smoothly, making it an excellent choice for HVAC, pumping, and automation.

Advanced Protection and User-Friendly Design

A robust multi-protection system, including overload, overvoltage, undervoltage, and short circuit safeguards, ensures equipment safety and operational continuity. The user-friendly interface and programmable inputs facilitate customization for a range of applications. The compact design and IP65-rated enclosure provide durability and easy installation in challenging industrial settings.

FAQ's of MD600S INOVANCE DRIVE 0.5 HP:

Q: How does the MD600S INOVANCE DRIVE 0.5 HP enhance motor control?

A: The MD600S drive incorporates both V/F control and sensorless vector control, which allows for precise regulation of motor speed and improved torque performance, particularly during low-speed start-up. This ensures smoother motor operation and greater efficiency in industrial applications.

Q: What types of applications are suitable for the MD600S drive?

A: This drive is ideal for controlling motors in various industrial systems, including HVAC, pumps, fans, and automation processes. Its versatile features and strong protection levels make it suitable for environments that require dependable performance and flexibility.

Q: When should I use the built-in braking unit?

A: The built-in braking unit is particularly beneficial when quick deceleration or stopping of the motor is required, such as in applications involving frequent starts and stops or heavy loads. This feature helps prolong equipment life and enhances safety.

Q: Where can the MD600S INOVANCE DRIVE be installed?

A: The drive's IP65 rating and compact, wall- or panel-mountable design enable installation both in controlled indoor environments and harsher industrial settings with exposure to dust, moisture, or vibration.

Q: What is the process for configuring and using this drive?

A: Users can configure the drive through its user-friendly 7-segment LED interface, utilizing programmable digital/analog inputs and connecting via RS485 with Modbus support. Quick installation is facilitated by screw terminal connections and terminal block design.

Q: What benefits does the alarm system provide?

A: The multi-protection alarm system constantly monitors for faults such as overload, overvoltage, undervoltage, and short circuits, providing instant fault response and displaying error codes. This minimizes downtime and protects connected motors and systems from potential damage.

Q: How energy efficient is the MD600S drive?

A: Featuring up to 98% efficiency and automatic adjustment according to load, the MD600S drive reduces energy consumption, lowers operational costs, and maintains a high power factor (0.98), making it highly efficient for continuous industrial use.
